CPU? ARM Cortex?-A7
Video
? Supports 1080p@60fps or 2-channel 1080p@30fps H.264 video
encoding, supports 8M JPEG encoding
? Supports H.264 1080p@60fps decoding, MJPEG 1080@30fps decoding
? Supports H.264 1080p@30fps +720P@30fps + 720P@30fps + VGA30fps
encoding
Video Input/Output
? Supports 8/10/12-bit
parallel CSI and 4-lane MIPI CSI2
? Supports BT1120 input
? Supports up to 8M CMOS
sensor
? Supports RGB/i80/LVDS LCD up
to 1024x768 resolution
? Supports Allwinner's
next-gen SmartColor display technology for better visual effects for images
& videos
|
ISP
? Integrated ISP up to 8M
pixels
? Supports two channel outputs
for display and encoding respectively
? Supports various input and
output formats
? Supports AE/AF/AWB
? Supports saturation
adjustment/ noise reduction/ defect pixel correction/distortion correction
Memory
? Supports 16-bit
DDR3/LPDDR3/DDR3L SDRAM controller, up to 1333Mbps
? Supports 16-bit DDR2 up to
800Mbps, 16-bit LPDDR2 up to 1066Mbps
? Supports memory size up to
2GB
OS
? Supports Camdroid OS, an
Android-lite operating system
? Supports Linux OS
|
Audio Codec
? Integrated 92dB audio codec
? Supports two ADC channels
and two DAC channels
? Supports 3 MIC-in, a stereo
Line-in, a headphone output and a stereo line-out output
Connectivity
? 3 x SD card controllers
? LRADC/SPI/TWI/UART/PWM
? USB, EMAC+PHY
Package? TFBGA
259 pins, 12mm x 12mm, 0.65 pitch
|
